Results 1-12 of 2212This is a basic design for an aquarium stand that I have built twice, once for a 55 gallon, and once for a 120 gallon. The design could be modified for virtually any glass tank in the 55 to 180 or so gallon range by simply adjusting the length and width. The pictures are from the construction of the stand for my 120 gal unless otherwise indicated. I assume that you have a basic knowledge of how to measure, cut, drill, nail, screw, glue, etc. I also assume that you know proper safety precautions. If you do not know either, please refer to a basic carpentry book. Plan to spend several evenings on this project. It took me about a week working 2 to 3 hours an evening to finish the project. If you are inexperienced at woodworking, plan to take up to twice as long. I start by building a basic frame using 2x4s. As seen in the picture below, the frame consists of two rectangles (top and bottom), vertical posts, and cross-beams. The rectangles should be as long and wide as your tank plus 1/2 inch for wiggle room in each direction.

The Cross braces should be placed at two foot intervals. Since the pictured stand is only 4 feet long, there is only one cross-brace at the center of each rectangle. Vertical posts should be placed at each corner, and at each cross-brace location. Decide what height you want the top of the tank to be at,and subtract the tank height to get the length of the vertical posts. fish tank stand supportFor my 120, I made the vertical posts about 40 inches long. fish tank light australiaThis makes a fairly tall stand, but I wanted the tank to be at a higher line of sight.fish tank stand price in mumbai Joints are connected using wood glue and #8×2” wood screws. fish tank led ornaments

Drill pilot holes and couter-sink them. If you do not have a power drill, it would be a good idea to get one. Screwing in 2” wood screws by hand is a very difficult job, even with pilot holes. A screwdriver bit turns your drill into a power screw driver. To the basic frame, I added nailers. small fish tank price in indiaThe purpose of the nailers is to provide a continuous surface for attaching the cover material. juwel fish tank 125As shown in the picture below, there is a nailer atached to each vertical support. The nailers are atached to the supports with glue and wood screws. Measure the distance between the upper and lower rectangles to get the length for the nailers. The picture also shows some extra frame work I did for the openings on the front of the tank. This was to create openings that were the right size for the doors I bought, and to give me solid locations to mount the doors.

I will talk more about the doors later. The final feature shown in the picture below is the panel covering the bottom of the frame. This is a tricky cut. You will need to measure all the obstructions (vertical post locations) insied the frame fairly closely. Draw them out with a pencil on a piece of cover material and cut out carefully with a hand jig saw (a rotary saw or hand coping saw could also be used if you do not have a hand jigsaw). The piece is attached with glue and 3d finishing nails. Now comes the task of covering the frame. It is simply a matter of measuring, marking and cutting the sheeting. Try to lay out the cover pieces so that you get the most from each sheet of material. Glue and nail with 3d finish nails. If you want to hide the nail heads, sink them with a center punch, and fill the holes with wood putty. Note that the back of the frame does not need to be covered unless it will be exposed to view. Now comes the trim. Again, measure each pice, and cut carefully to get a good fit.

If you have the skill and a miter box, you can miter the trim corners. If not, just do lap joints. If you do lap joints, cut the front trim so that it is long enough to cover the ends of the side trim. That way, the joints face to the side, rather than the front. My preference is to have the top trim conceal the frame of the tank, particularly if the frame is a different color than the finished stand. Here is a pic with more of the trim applied: Once the trim is done, it is time to finish the wood. I used a light oak polyurethane stain. You can select your finish based on the material you are using and the trim on the tank. Below is the stand with one coat of finish. The pre-fab doors are laying across the top of the stand to dry. Depending on the finish you select, you will probably need from 1 to 3 coats of finish. Follow the directions as far as sanding between coats. When you are done with the finish, atach the doors, and you are done: Some other features that may make your stand more useful include shelves, lights, and outlet strips.

For my 55 gallon tank, I used a slightly altered design. If felt that the tank might be a little top heavy if the stand had the same footprint as the tank. Accordingly, I built out the base into a pedestal using extra layers of 2x4s around the bottom. I then covered this pedestal in a similar fashion to the main frame. This is the end result:)submitted by π Rendered by PID 40357 on app-421 at 2017-04-25 19:32:28.999905+00:00 running 1b1b8c2 country code: SG. Decorative Aquarium Lifelike Artificial Coral Plants for Fish Tank - Purple + Orange Aquarium Tank Simulation Swimming Fish - Red + Yellow + Blue (6 PCS) Lifelike Emulation Big Jellyfish Toy for Aquarium Fish Tank - Blue Silicone Aquarium Emulate Cuttlefish - Orange + White + Multi-Colored Aquarium Fish Tank Air Pipe One-Way Check Valves - Black + White (20 PCS) Aquarium Fish Tank Cover Board Holder Clip - Transparent (4 PCS) BrandN/A ModelN/AQuantity4 piece(s) per packColorTransparent MaterialAcrylic SpecificationMax.
